Marantz PM7000N Integrated Amplifier Review

Marantz PM7000N is not just a classic, analog mid-range integrated amplifier. Marantz comes with digital inputs and the group-wide Enrich streaming with HEOS technology. The Marantz PM7000N is a multifunctional device that – with many additional benefits – ensures the connection to the digital present. By testing the streaming amp, we answered another question: Can the brand-new
Home Bluetooth speakers from a well-known company like Denon be integrated into the music
system without any problems. Yes.

Idea Marantz PM7000N

If you need a solid, classic integrated amplifier, you have come to the right place. I know you might
be wondering why buy an external streamer if you can have it integrated immediately, without giving the device the characteristics of a receiver. It is precisely this concept that brings some benefits to daily usage. I will explain this with an example. If you connect your LED to the given optical input, the system automatically switches on with the LED.

The LED plays over the system just like over a soundbar, just better. If you want to listen to classic CDs, even SACDs, or records occasionally while working or on the terrace or just enjoying the weekend with a glass of wine then HEOS connectivity does it for you. But we start with the classic connections.

Marantz PM7000N Integrated Amplifier ReAR VIEW
Marantz PM7000N Integrated Amplifier Review

The Rear panel reveals the inner structure of the Marantz PM7000N quite well. Marantz PM7000N comes
with WLAN/Bluetooth antenna sockets and a narrow line of digital connections with LAN. The rest is the classic analog integrated amplifier. At the same price, the Marantz PM8006 has double speaker terminals, preamp and power amp sockets, and a slightly more complex wired phono stage. It is aimed at pure analog fans. The Marantz PM7000N, on the other hand, offers a digital setup right away, without omitting important things.

Marantz PM7000N also offers one more useful feature a subwoofer output. This has a sum signal with a switchable low-pass frequency. Unfortunately, that is inconsistent: either you filter on the subwoofer or – better – you have all the bass management setup and can also filter the speakers, Sadly which is not
the case here.

Inside Look Marantz PM7000N

If you carefully open the screws and remove the upper case but I will recommend you do this because by doing this your official Marazntz guarantee will expire, Here’s the inner view of Marantz PM7000N electronics opens up. The Marantz PM7000N integrated amplifier is divided into three parts: 1. The power supply, The power amplifiers with large cooling fins, and the small signal department.

Above the analog section with a separate phono circuit board, isolated in the metal cage, is the digital signal processing, from which only the cooling of the HEOS module looks open at the top. A D/A converter chip AK4490 handles the analog transformation for signals up to 192 kilohertz sampling
rate or DSD streams up to 5.6 megahertz.

In the preamplifier and phono stage, Marantz uses HDAM driver stages instead of the usual and old operational amplifier ICs. These HDAMs reduce noise and improve the range of frequencies to provide better sound quality. If you look under the chassis, you’ll see a base plate. The high-quality plastic feet
are thick and have small felt washers underneath, allowing them to rest slightly above the surface of
your rack or table.

Streaming and Configuration

You can use Marantz PM7000N in the classic way on the device, with the remote control or with the HEOS app. The infrared handheld transmitter is pleasantly ergonomic and, in addition to the amplifier functions, also controls the streaming music sources or a Marantz CD player.

OLED display in the front of Marantz PM7000N allows a very clear operation and navigation in the music or on the server. Thanks to OLED technology, the display always offers a very good contrast that is not dependent on the viewing angle. While not particularly bright but its good because when you’re enjoying music in dim lighting, the display light doesn’t irritate, it is crystal clear to read. The engineers of Marantz animated the display nicely

However, what convinces many buyers of the Marantz PM7000N is how easily it works with HEOS. Marantz PM7000N is linked to three digital inputs and has the option of adding music via a USB memory stick or hard drive without having to connect to another device. Another good feature is that HEOS even allows you voice control via Alexa or Google Assistant. You can easily play your mobile music or even if you want to hear the sound of YouTube concerts in large format can send signals via the antennas using Bluetooth or Airplay 2.

Sound

According to the specifications, the Marantz PM7000N delivers 60 watts per channel. But in reality, it performs much better than expected. Even though it’s rated at 60 watts, it’s only slightly less powerful than a 120-watt system, about 3 decibels less. This means it still packs a punch and delivers energetic and dynamic sound, making instruments like snare drums and vibraphones sound lively and clear between the speakers. The soundstage, or the space where the music seems to come from, is also impressive. It feels deep and wide, giving you a sense of being surrounded by the music. Instruments usually sound like they’re behind the speakers, and singers sound like they’re in front, creating a clear and immersive listening experience.

The PM7000N impressively handles even mono recordings, like the classic ’56 Ella and Louis, which I often use as a natural benchmark (recordings made without modern studio enhancements). With this Marantz model, the brightest parts of the sound are slightly toned down compared to other models, such as the Yamaha A-S701 or the Onkyo A-9010. It’s like the cymbals and high hats are illuminated by soft candlelight instead of bright spotlights. However, this subtle dimming effect adds to the enjoyment and is a characteristic feature of most Marantz products.


The Marantz PM7000N’s headphone output Sounds Awesome without being too forceful or laid-back. It delivers tight, detailed sound with rich tones across the spectrum. Another great feature is the large headphone jack, which provides ample power reserves and can drive almost any headphone to its maximum potential.

Conclusion


With the Marantz PM7000N, there’s no need to talk about finding a balance between digital and analog
it effortlessly integrates both worlds. It brings together reel-to-reel classics, vinyl, digital audio, and streaming seamlessly. The HEOS multiroom and streaming system is mature, allowing you to distribute music from various sources throughout your home without needing a complicated AV receiver. Marantz PM7000N doesn’t disappoint in sound quality—it’s powerful, and dynamic, with excellent soundstage separation from the front to the back. It’s a modern, hassle-free device that delivers great audio enjoyment.

As for criticisms, there are just a couple: the subwoofer control could be more consistent, and while the build quality is good, it’s not quite as flawless as some other Marantz devices in this price range.
